Compatible with SC, LC, FC, MU, ST, MT-RJ, and E2000 connectors
PC, UPC, APC, and SPC polishing options available
Optional cable diameters: 0.9 mm, 2.0 mm, 3.0 mm
Single mode (9/125) and multimode (50/125, 62.5/125) fiber options
Supports simplex and duplex configurations
Low insertion loss and high return loss
Good interchangeability and long service life
FTTH and FTTx access networks
Telecom and data center fiber termination
Optical distribution frames (ODF) and patch panels
LAN and WAN network installations
Fiber splicing and network maintenance
| Item | SM(Single Mode) | MM(Multimode) | |||
| Fiber Cable Type | G652D/G655/G657A1/G657A2 | OM1 | OM2/OM3/OM4 | ||
| Fiber Diameter (um) | 9/125 | 62.5/125 | 50/125 | ||
| Cable OD (mm) | 0.9/1.6/1.8/2.0/2.4/3.0 | ||||
| Endface Type | PC | UPC | APC | UPC | UPC |
| Typical Insertion Loss (dB) | <0.2 | <0.15 | <0.2 | <0.1 | <0.1 |
| Return Loss (dB) | >45 | >50 | >60 | / | |
| Insert-pull Test (dB) | <0.2 | <0.3 | <0.15 | ||
| Interchangeability (dB) | <0.1 | <0.15 | <0.1 | ||
| Anti-tensile Force (N) | >70 | ||||
| Temperature Range (℃) | -40~+80 | ||||
|
Item
|
SM(Single Mode)
|
MM(Multimode)
|
|||
|
Fiber Cable Type
|
G652D/G655/G657A1/G657A2
|
OM1
|
OM2/OM3/OM4
|
||
|
Fiber Diameter (um)
|
9/125
|
62.5/125
|
50/125
|
||
|
Cable OD (mm)
|
0.9/1.6/1.8/2.0/2.4/3.0
|
||||
|
Endface Type
|
PC
|
UPC
|
APC
|
UPC
|
UPC
|
|
Typical Insertion Loss (dB)
|
<0.2
|
<0.15
|
<0.2
|
<0.1
|
<0.1
|
|
Return Loss (dB)
|
>45
|
>50
|
>60
|
/
|
|
|
Insert-pull Test (dB)
|
<0.2
|
<0.3
|
<0.15
|
||
|
Interchangeability (dB)
|
<0.1
|
<0.15
|
<0.1
|
||
|
Anti-tensile Force (N)
|
>70
|
||||
|
Temperature Range (℃)
|
-40~+80
|
||||
