48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable

จำนวนสั่งซื้อขั้นต่ำ : 1กิโลเมตร รายละเอียดการบรรจุ : กลองไม้
เวลาการส่งมอบ : 3-5 วัน เงื่อนไขการชำระเงิน : L/C, D/A, D/P, T/T, Western Union, MoneyGram
สามารถในการผลิต : 8000 กิโลเมตรต่อเดือน
สถานที่กำเนิด: กวางตุ้งจีน ชื่อแบรนด์: JQ/OEM/Customize
ได้รับการรับรอง: CE/ISO9001/RoHS/FCC หมายเลขรุ่น: GYTA33

ข้อมูลรายละเอียด

ประเภทสายเคเบิล: GYTA33 สถานที่กำเนิด:: กวางโจวจีน
จำนวนไฟเบอร์: 2-288คอร์ ประเภทไฟเบอร์: โหมดเดียว G652D หรือตามคำขอของคุณ
แบรนด์ไฟเบอร์: yofc/fiberhome/corning/fujikura จำนวนตัวนำ: ≥ 10
สมาชิกแข็งแกร่ง: ลวดเหล็ก/เส้นด้ายแก้ว FRP โครงสร้าง: ท่อหลวมควั่น
ติดอาวุธ: แจ็คเก็ตคู่หุ้มเกราะคู่ วัสดุของแจ็คเก็ต: PE หรือตามคำขอของคุณ
โครงสร้างสายเคเบิล: เกราะเทปอลูมิเนียมท่อหลายหลวม แอปพลิเคชัน: เรือดำน้ำใต้น้ำใต้ทะเล
อุณหภูมิในการทำงาน: -40 ~+60 ℃ ประเภทตัวเชื่อมต่อ: เอสซี/เอฟซี/ST/LC
การรับประกัน: มากกว่า 25 ปี การรับรอง: ROHS, REACH, SGS และ ISO รับรอง
วัสดุ: เส้นใยแก้วนำแสง ท่อหลวม: PBT
โหมด: โหมดเดี่ยวหรือหลายโหมด ฝัก: HDPE/LSZH
คุณสมบัติ: เทปอลูมิเนียมลูกฟูก จำนวนไฟเบอร์: 8
ผู้ผลิต: ใช่ เส้นผ่านศูนย์กลางแจ็คเก็ต: 12.8
ใช้: ท่อ/ อากาศ/ ใต้น้ำ/ ฝังศพโดยตรง วิธีการติดตั้ง: ทางอากาศ
สีปลอกหุ้มด้านนอก: สีดำ
เน้น:

48 core steel wire armored fiber optic cable

,

direct burial underwater fiber optic cable

,

GYTA33 submarine fiber optic cable

รายละเอียดสินค้า

The GYTA33 optical cable adopts a PBT loose tube design, where the optical fibers are housed and filled with thixotropic gel. At the center of the cable core lies a steel wire strength member, and for cables with higher core counts, a PE cushion layer is added. The loose tubes are stranded around the central strength member in an SZ pattern, with water-blocking compounds filling the interstices. The outer layer is reinforced with round steel wire armor and covered by a polyethylene sheath for enhanced protection.
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 0

The GYTA33 optical cable is designed for deployment in freshwater and shallow water environments. It can be laid directly without joints and is suitable for short-distance underwater communication.

Key Features:

  1. Strong resistance to mechanical stress and temperature variations.

  2. Steel wire armor provides high tensile strength.

  3. Longitudinal aluminum tape wrapping acts as an effective moisture barrier.

  4. Full cross-section water-blocking ensures protection against fresh or salt water intrusion.

  5. Outer jacket shields the cable from UV exposure.

  6. Flame-retardant sheath available upon request.

  7. Reliable operation when installed at depths up to 250 meters.

Product Specifications:
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 1
Package:
24 Core G652D GYTA33 Steel Armored Stranded Loose Tube Optical Fiber Cable
3km/Wooden Drum,Drum dimension 110*55*50cm,G.W 360.0kg.
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 2

FAQ

Q1: Are you a manufacturer or a trading company?
A1: We are a direct manufacturer.



Q2: Where is your factory located? How can I visit?
A2: Our factory is in Shenzhen, Guangdong Province. You can fly to Shenzhen or Guangzhou airport, and provide us with your flight number—we’ll arrange pickup.



Q3: Can I order samples?
A3: Of course! Sample orders are welcome for testing our quality and service.



Q4: What is the warranty period?
A4: All products come with a 12-month warranty.



Q5: What payment options do you support?
A5: We accept L/C, T/T, PayPal, Western Union, and MoneyGram.



Q6: Do you offer OEM/branding services?
A6: Yes, we provide professional OEM service. For bulk orders, custom logo printing is free of charge.
